Vertiv Liebert ITON CX UPS | 600VA | 230V | 1 x 7AH battery
Overview
Vertiv Liebert ITA2 10KVA UPS 220/230/240VAC 1x1 380/400/415VAC 3x1 long backup
Single Phase Input | Three Phase Input | Compact Efficient Robust UPS for Critical Applications | Gravity LCD Screen | Rack-tower design for installation flexibility
The Vertiv Liebert ITA2 is a fully-digital, highly reliable, double-conversion UPS solution that provides clean and consistent power. This highly efficient solution is ideal for various deployments, including IT racks, network closets, automation control systems, and precision instruments to small sized control rooms among other edge applications. Its cutting-edge design enables seamless integration into various ecosystems. This UPS offers single-phase and economical three-phase power for critical loads. It is tailored for global deployment in a low carbon, compact footprint. This intelligent UPS has scalable battery runtimes, output distribution options, a high power factor and an optional maintenance bypass cabinet. With rackmount or tower configuration, it is easy to install and operate.
Gallery
Manufacturer-Brochure
Specifications
General informations
Manufacturer :
Vertiv
Manufacturer Part Number:
505101079020
Manufacturer Website Address:
http://www.vertiv.com/
Brand Name:
Vertiv Liebert
Product Series:
ITA2
Product Name:
ITA2 10kVA Rack/tower UPS
Marketing Information:
The Vertiv Liebert ITA2 is a fully-digital, highly reliable, double-conversion UPS solution that provides clean and consistent power. This highly efficient solution is ideal for various deployments, including IT racks, network closets, automation control systems, and precision instruments to small sized control rooms among other edge applications. Its cutting-edge design enables seamless integration into various ecosystems. This UPS offers single-phase and economical three-phase power for critical loads. It is tailored for global deployment in a low carbon, compact footprint. This intelligent UPS has scalable battery runtimes, output distribution options, a high power factor and an optional maintenance bypass cabinet. With rackmount or tower configuration, it is easy to install and operate.
Product Type:
Double Conversion Online UPS
Technical information
Plug/Connector Type:
- Hard Wire 2-wire
- Hard Wire 4-wire
Receptacle Type:
Terminal Block
Protection Type:
Surge
Phase:
Single Phase/Three Phase
Application/Usage:
- IT Rack
- Network Closet
- Automation System
- Precision Instrument
- Control Room
- Data Center
- Server
- Workstation
- Telecommunication
- Network
- Critical System
Efficiency:
95.8%
Power Description
Load Capacity (VA):
10 kVA
Input Voltage:
- 120 V AC
- 230 V AC
- 380 V AC
- 400 V AC
- 415 V AC
Input Voltage Range:
- 176 V AC - 288 V AC
- 100 V AC - 176 V AC
Output Voltage:
- 220 V AC
- 230 V AC
- 240 V AC
- 380 V AC
- 400 V AC
- 415 V AC
Input Frequency:
- 50 Hz
- 40 Hz
- 70 Hz
- 60 Hz
Output Frequency:
- 50 Hz
- 60 Hz
Input Power Factor:
0.99
Output Power Factor:
1
Display & Graphics
Display:
LCD
Environmental Conditions
Maximum Operating Temperature:
50°C
Storage Relative Humidity:
5% - 95%
Sound Emission (A-Weighted):
55 dB(A)
Physical Characteristics
Form Factor:
Rack/Tower
Rack Height:
2U
Height:
8.50 cm (3.35")
Width:
43 cm (16.93")
Depth:
56 cm (22.05")
Weight (Approximate):
15 kg
Miscellaneous
Certifications & Standards:
- IEC/EN 62040-1
- IEC/EN 62040-2
- VFI-SS-111
Energy Star:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
