Vertiv Liebert ITON CX UPS | 600VA | 230V | 1 x 7AH battery
Overview
Vertiv Liebert ITA2 1kVA UPS 220VAC LCD long backup model with SNMP card
Compact Efficient Robust UPS for Critical Applications | LCD Screen | Rack-tower design for installation flexibility | Flexible power protection
The Vertiv™ Liebert® ITA2 (1-3 kVA) series is a transformer-free UPS designed to offer compact, efficient, and reliable power to modern sensitive electronic equipment. With a unity output power factor, the ITA2 matches the needs of modern IT loads, and with its wide input voltage and frequency range, it helps reduce the need for battery intervention, and can help extend battery life. It offers best-in-class efficiency of up to 94% in double conversion mode over a wide range of load conditions which help contribute to OPEX cost savings. The ITA2 features a multi-lingual LCD user interface allowing close control and monitoring of system status and performance. ITA2 has been rigorously tested under extreme conditions like dusty environments, high altitude, very high and low ambient temperatures, and seismic conditions among others. These capabilities make the ITA2 an ideal choice for a wide range of commercial applications.
Gallery
Manufacturer-Brochure
Specifications
General informations
Manufacturer :
Vertiv
Manufacturer Part Number:
504900139000
Manufacturer Website Address:
http://www.vertiv.com/
Brand Name:
Vertiv Liebert
Product Series:
ITA2
Product Name:
ITA2 1kVA Rack/tower UPS
Marketing Information:
The Vertiv™ Liebert® ITA2 (1-3 kVA) series is a transformer-free UPS designed to offer compact, efficient, and reliable power to modern sensitive electronic equipment. With a unity output power factor, the ITA2 matches the needs of modern IT loads, and with its wide input voltage and frequency range, it helps reduce the need for battery intervention, and can help extend battery life. It offers best-in-class efficiency of up to 94% in double conversion mode over a wide range of load conditions which help contribute to OPEX cost savings. The ITA2 features a multi-lingual LCD user interface allowing close control and monitoring of system status and performance. ITA2 has been rigorously tested under extreme conditions like dusty environments, high altitude, very high and low ambient temperatures, and seismic conditions among others. These capabilities make the ITA2 an ideal choice for a wide range of commercial applications.
Product Type:
Double Conversion Online UPS
Technical information
Receptacle Type:
Terminal Block
Transfer Time:
0 ns
Efficiency Detail:
- 98% (ECO Mode)
- 94% (Dual Conversion Mode)
Application/Usage:
- Critical System
- Commercial
- Computer
- Workstation
- Server Room
- Data Center
- Network Closet
- VoIP
Surge Suppression:
Yes
Power Description
Load Capacity (VA):
1 kVA
Load Capacity (Watt):
1 kW
Input Voltage:
- 120 V AC
- 230 V AC
Input Voltage Range:
- 176 V AC - 288 V AC
- 100 V AC - 176 V AC
Output Voltage:
- 220 V AC
- 230 V AC
- 240 V AC
Input Frequency:
- 50 Hz
- 40 Hz
- 70 Hz
Waveform Type:
Sinusoidal
Input Power Factor:
0.99
Output Power Factor:
1
Display & Graphics
Display:
LCD
Management
Network Management:
SNMP/HTTP Remote Monitoring
Interfaces/Ports
Network (RJ-45):
Yes
USB:
Yes
Battery Information
DC System Voltage:
36 V DC
Battery Characteristics:
Maintenance-free, Sealed
Battery Chemistry:
Lead Acid
Environmental Conditions
Minimum Operating Temperature:
0°C
Maximum Operating Temperature:
50°C
Storage Temperature:
-15°C - 40°C
Storage Relative Humidity:
5% - 95%
Physical Characteristics
Height:
8.50 cm (3.35")
Width:
43 cm (16.93")
Depth:
40 cm (15.75")
Rack Height:
2U
Form Factor:
Rack/Tower
Weight (Approximate):
7.10 kg
Miscellaneous
Certifications & Standards:
- IEC/EN 62040-1:2008+A1:2013
- Conducted Emission:IEC/EN 62040-2 C2, Harmonic current:IEC/EN 61000-3-2
- IEC/EN 61000-4-5
Energy Star:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
